Mixture and Alligation is one of those quantitative chapters that looks intimidating until you master the single visual rule that governs almost every question in the topic.
That rule is the Alligation Cross-Subtraction Rule—and once you internalize it, problems that look like multi-variable algebra equations collapse into two-step mental subtractions. Whether a question involves blending two grades of tea, diluting milk with water, combining two student groups with different average scores, or calculating overall profit across two items, the exact same diagram works every time.
In SSC CGL, Mixture and Alligation typically contributes 2–3 questions in Tier 1 and 3–4 questions in Tier 2.
In IBPS PO & SBI PO, it appears both as standalone Prelims questions and inside high-scoring Mains Arithmetic DI sets.
In CAT, alligation shortcuts save critical minutes on weighted averages, concentrations, and speed-time-distance problems.
This guide covers every tested configuration—basic alligation, reverse alligation (gap-splitting), vessel replacement, successive dilution, and non-price applications—with step-by-step worked examples and exam traps.
Part 1: The Alligation Rule — The One Visual Framework You Need
What Is Alligation?
Alligation is a rapid visual method used to find the ratio in which two ingredients at different unit values (prices, concentrations, percentages, or averages) must be mixed to produce a mixture with a target mean value ($m$).
The Cross-Subtraction Formula & Diagram
Suppose two ingredients $A$ and $B$ are mixed:
Cheaper / Lower Value ($d_1$): Unit value of Ingredient $A$
Dearer / Higher Value ($d_2$): Unit value of Ingredient $B$
Mean Value ($m$): Unit value of the final mixture (always lies strictly between $d_1$ and $d_2$, i.e., $d_1 < m < d_2$)
- Cheaper (d₁) Dearer (d₂)
\ /
\ /
Mean (m)
/ \
/ \
(d₂ − m) (m − d₁)
[Parts of A] [Parts of B]
$$\frac{\text{Quantity of Cheaper } (A)}{\text{Quantity of Dearer } (B)} = \frac{d_2 - m}{m - d_1}$$
Golden Memory Rule: Always subtract toward the center (so both differences remain positive). The left bottom value gives the parts of the left (cheaper) ingredient, and the right bottom value gives the parts of the right (dearer) ingredient.
Worked Example 1 (Equal Ratio): Tea costing ₹60/kg is mixed with tea costing ₹90/kg to produce a blend worth ₹75/kg. Find the mixing ratio.
Here $d_1 = 60$, $d_2 = 90$, and $m = 75$.
$\text{Cheaper parts} = 90 - 75 = 15$ | $\text{Dearer parts} = 75 - 60 = 15$
$\text{Ratio} = 15 : 15 = \mathbf{1 : 1}$ (Check: $\frac{60(1) + 90(1)}{2} = \textbf{₹75/kg}\ \checkmark$).
Worked Example 2 (Unequal Prices): Rice at ₹40/kg is mixed with rice at ₹65/kg to obtain a mixture worth ₹50/kg. Find the ratio of mixing.
Here $d_1 = 40$, $d_2 = 65$, and $m = 50$.
$\text{Cheaper parts} = 65 - 50 = 15$ | $\text{Dearer parts} = 50 - 40 = 10$
$\text{Ratio} = 15 : 10 = \mathbf{3 : 2}$ (Check: $\frac{40(3) + 65(2)}{5} = \frac{250}{5} = \textbf{₹50/kg}\ \checkmark$).
Part 2: Finding the Mean Value (Weighted Average & Gap-Splitting)
When the quantities (or ratio) of the two ingredients are given and you need to find the final mixture value ($m$), you have two fast methods:
Method 1: Weighted Mean Formula
$$m = \frac{Q_1 V_1 + Q_2 V_2}{Q_1 + Q_2}$$
Worked Example 3: $20\text{ litres}$ of milk at ₹18/litre is mixed with $30\text{ litres}$ of milk at ₹23/litre. Find the price of the mixture per litre.
$m = \frac{(20 \times 18) + (30 \times 23)}{20 + 30} = \frac{360 + 690}{50} = \frac{1,050}{50} = \textbf{₹21/litre}$
Method 2: Reverse Alligation ("Gap-Splitting" Shortcut — CAT & IBPS Favorite)
Instead of multiplying large numbers, divide the gap between the two values ($d_2 - d_1$) in the inverse ratio of their quantities:
Worked Example 4: $40\text{ litres}$ of a $30\%$ acid solution is mixed with $60\text{ litres}$ of a $50\%$ acid solution. Find the final concentration.
Ratio of quantities $A : B = 40 : 60 = \mathbf{2 : 3}$ ($5$ total parts).
Total gap between concentrations $= 50\% - 30\% = 20\%$.
Divide the $20\%$ gap into $5$ parts $\implies 1\text{ part} = 4\%$.
Since Solution $B$ has the larger quantity ($3$ parts), the mean sits closer to $50\%$:
$$m = 30\% + (3 \times 4\%) = \mathbf{42\%}$$
Part 3: Finding Exact Quantities When Total Mixture Is Given
Use the Alligation diagram to find the mixing ratio $a : b$.
Sum the ratio parts: $\text{Total Parts} = a + b$.
Multiply each fraction ($\frac{a}{a+b}$ and $\frac{b}{a+b}$) by the total volume/weight.
Worked Example 5 (Water & Milk): In what ratio must free water (₹0/litre) be mixed with pure milk at ₹30/litre to reduce the cost to ₹20/litre? How much of each is required to make $50\text{ litres}$ of mixture?
Step 1 (Alligation): $d_1 = 0$, $d_2 = 30$, $m = 20$.
$\text{Water} : \text{Milk} = (30 - 20) : (20 - 0) = 10 : 20 = \mathbf{1 : 2}$.
Step 2 (Quantities for $50\text{ litres}$):
$\text{Water} = \frac{1}{3} \times 50 = \mathbf{16.67\text{ litres}}$ | $\text{Milk} = \frac{2}{3} \times 50 = \mathbf{33.33\text{ litres}}$.
Worked Example 6 (Three-Ingredient Weighted Mean): A grocer blends $10\text{ kg}$ of sugar at ₹15/kg, $15\text{ kg}$ at ₹20/kg, and $25\text{ kg}$ at ₹25/kg. Find the average cost per kg.
$m = \frac{(10 \times 15) + (15 \times 20) + (25 \times 25)}{10 + 15 + 25} = \frac{150 + 300 + 625}{50} = \frac{1,075}{50} = \textbf{₹21.50/kg}$
Part 4: Replacement in Vessels — The Most Tested Subtopic
Replacement questions are the highest-frequency mixture problems in SSC CGL, IBPS PO, and SBI PO. A vessel starts with a pure liquid (or known mixture); a fixed quantity $r$ is drawn out and replaced with another liquid (usually water), repeated $n$ times.
The Master Replacement Formula
$$\text{Final Quantity of Original Liquid} = \text{Initial Quantity} \times \left(1 - \frac{r}{V}\right)^n$$
(where $V =$ total volume of the vessel, $r =$ volume removed and replaced each time, and $n =$ number of operations).
Worked Example 7 (Single Replacement): A vessel holds $40\text{ litres}$ of pure milk. $8\text{ litres}$ is drawn out and replaced with water. Find the remaining milk.
$\text{Milk Remaining} = 40 \times \left(1 - \frac{8}{40}\right)^1 = 40 \times \frac{4}{5} = \mathbf{32\text{ litres}}$
Worked Example 8 (Multiple Replacements): A cask contains $50\text{ litres}$ of pure milk. $10\text{ litres}$ is removed and replaced with water three times. How much milk remains?
$\text{Milk Remaining} = 50 \times \left(1 - \frac{10}{50}\right)^3 = 50 \times \left(\frac{4}{5}\right)^3 = 50 \times \frac{64}{125} = \mathbf{25.6\text{ litres}}$
Worked Example 9 (Finding Number of Operations $n$): From a drum containing $64\text{ litres}$ of milk, $16\text{ litres}$ is replaced with water $n$ times, leaving $27\text{ litres}$ of milk. Find $n$.
$\frac{\text{Final Milk}}{\text{Initial Milk}} = \left(1 - \frac{16}{64}\right)^n \implies \frac{27}{64} = \left(\frac{3}{4}\right)^n$
Since $\left(\frac{3}{4}\right)^3 = \frac{27}{64}$, we get $\mathbf{n = 3\text{ operations}}$.
IBPS Mains & Tier 2 Trap (Unequal Removal & Addition): The formula $\left(1 - \frac{r}{V}\right)^n$ works only when the volume removed equals the volume added (keeping total volume $V$ constant). If $10\text{ litres}$ is removed from $50\text{ litres}$ and $20\text{ litres}$ of water is added, track the pure milk step by step: $\text{Milk} = 50 \times \frac{40}{50} = 40\text{ litres}$ out of a new total volume of $60\text{ litres}$ ($\mathbf{2 : 1}$ milk-to-water ratio).
Part 5: Successive Dilution & Ratio Mixtures
When a problem expresses concentration as a percentage or ratio instead of pure volume, apply the exact same scaling factor $\left(1 - \frac{r}{V}\right)^n$ directly to the initial concentration:
Worked Example 10 (Percentage Concentration): An $80\text{-litre}$ tank holds a $90\%$ alcohol solution. Twice, $20\text{ litres}$ is drawn out and replaced with pure water. Find the final alcohol percentage.
$\text{Final Concentration} = 90\% \times \left(1 - \frac{20}{80}\right)^2 = 90\% \times \left(\frac{3}{4}\right)^2 = 90\% \times \frac{9}{16} = \mathbf{50.625\%}$
Worked Example 11 (Mixture Starting as a Ratio): A $60\text{-litre}$ vessel contains milk and water in the ratio $5 : 1$. $12\text{ litres}$ of mixture is removed and replaced with water once. Find the new ratio.
Shortcut Method: Initial milk fraction $= \frac{5}{6}$. Removing $12\text{ litres}$ out of $60\text{ litres}$ leaves $\left(1 - \frac{12}{60}\right) = \frac{4}{5}$ of the existing milk:
$$\text{New Milk Fraction} = \frac{5}{6} \times \frac{4}{5} = \frac{4}{6} = \frac{2}{3}$$
Since milk is $\frac{2}{3}$ of the vessel, water is $1 - \frac{2}{3} = \frac{1}{3} \implies \text{New Ratio} = \mathbf{2 : 1}$.
Part 6: Alligation Applied Beyond Price (Averages, Profit & Speed)
Alligation works on any linear weighted average—not just rupees per kilogram:
1. Group Averages
Worked Example 12: The average age of Group A ($28$ students) is $25\text{ years}$, and the average age of Group B is $35\text{ years}$. If the combined average of both groups is $28\text{ years}$, find the number of students in Group B.
$d_1 = 25$, $d_2 = 35$, $m = 28$.
$\text{Ratio } A : B = (35 - 28) : (28 - 25) = \mathbf{7 : 3}$.
Since $7\text{ parts} = 28\text{ students} \implies 1\text{ part} = 4 \implies \text{Group B} = 3 \times 4 = \mathbf{12\text{ students}}$.
2. Pass & Profit Percentages
Worked Example 13 (Pass Percentage): In Section A, $60\%$ of students passed; in Section B, $80\%$ passed. Overall, $65\%$ passed. Find the ratio of students in A to B.
$\text{Ratio } A : B = (80 - 65) : (65 - 60) = 15 : 5 = \mathbf{3 : 1}$.
Worked Example 14 (Profit Percentage): A trader sells Variety 1 at $20\%$ profit and Variety 2 at $35\%$ profit to earn $30\%$ overall profit. Find the mixing ratio.
$\text{Ratio} = (35 - 30) : (30 - 20) = 5 : 10 = \mathbf{1 : 2}$.
3. Time, Speed & Distance (Critical Denominator Rule!)
When applying alligation to Average Speed ($\text{Speed} = \frac{\text{Distance}}{\text{Time}}$), the resulting ratio is always the ratio of the denominators—i.e., the TIME spent at each speed, never the distance ratio!
Part 7: Special Cases & Classic Exam Traps
Trap 1: Selling Adulterated Milk at Cost Price (1-Second Shortcut)
When pure milk is mixed with free water (₹0) and sold at the exact cost price of pure milk to earn $P\%$ profit:
$$\text{Ratio of Water to Milk} = P : 100$$
Worked Example 15: Milk costing ₹48/litre is mixed with water and sold at ₹48/litre to gain $20\%$ profit. Find the ratio of water to milk.
Direct Shortcut: $\text{Water} : \text{Milk} = 20 : 100 = \mathbf{1 : 5}$.
(Verification via Alligation: Mean $\text{CP} = \frac{48}{1.20} = \textbf{₹40/litre} \implies (48 - 40) : (40 - 0) = 8 : 40 = \mathbf{1 : 5}\ \checkmark$).
Trap 2: Mixing Three Varieties via Dual Alligation
Worked Example 16: Three varieties of rice costing ₹20/kg, ₹30/kg, and ₹40/kg are mixed to get a blend worth ₹28/kg. Find a valid mixing ratio.
Pair 1 (₹20 and ₹40 around ₹28) $\rightarrow (40 - 28) : (28 - 20) = 12 : 8 = \mathbf{3 : 2}$.
Pair 2 (₹30 and ₹40 around ₹28 is impossible since both exceed ₹28; pair ₹20 and ₹30 around ₹28 instead) $\rightarrow (30 - 28) : (28 - 20) = 2 : 8 = \mathbf{1 : 4}$.
Add the parts of the common ₹20 variety ($3 + 1 = 4$): $\text{Ratio }$ (₹20 : ₹30 : ₹40) $= \mathbf{4 : 4 : 2 = 2 : 2 : 1}$ (Check: $\frac{20(2) + 30(2) + 40(1)}{5} = \frac{140}{5} = \textbf{₹28/kg}\ \checkmark$).
Trap 3: "How Much Water Must Be Added?"
Worked Example 17: How much water must be added to $30\text{ litres}$ of milk worth ₹24/litre so that the resulting mixture is worth ₹20/litre?
$\text{Water} : \text{Milk} = (24 - 20) : (20 - 0) = 4 : 20 = \mathbf{1 : 5}$.
Since $5\text{ parts (milk)} = 30\text{ litres} \implies 1\text{ part (water)} = \mathbf{6\text{ litres}}$.
Exam Pattern & 3-Week Practice Plan
Weightage Across Major Competitive Exams
Exam | Expected Questions | Most-Tested Question Types |
|---|---|---|
SSC CGL Tier 1 | $2\text{--}3$ Qs | Basic alligation, mean price, 1-step vessel replacement |
SSC CGL Tier 2 | $3\text{--}4$ Qs | Multi-step successive replacement, profit + alligation traps |
IBPS PO / SBI PO Prelims | $1\text{--}2$ Qs | Water-milk adulteration, ratio of mixing |
IBPS PO / SBI PO Mains | $2\text{--}3$ Qs | Unequal replacement, caselet/DI mixture sets |
CAT QA & DILR | $1\text{--}2$ Qs | Reverse alligation (gap-splitting), weighted averages & concentration |
3-Week Mixture & Alligation Mastery Schedule
Week | Weekly Focus Area | Daily Timed Practice Target |
|---|---|---|
Week 1 | Cross-Subtraction Rule & Gap-Splitting (Price, ratio & reverse alligation) | $15$ problems/day ($20$ mins) |
Week 2 | Vessel Replacement & Successive Dilution (Single, multiple & unequal steps) | $12$ problems/day ($20$ mins) |
Week 3 | Averages, Profit Traps & Mixed Exam Sets (T.S.D. time ratios & DI sets) | $15$ mixed exam Qs/day ($25$ mins) |
(Daily Speed Tip: Pair your practice with a 10-minute warm-up on SpeedMath.in drilling ratio reductions, fraction-to-percentage conversions, and cubes—so calculating $\left(\frac{4}{5}\right)^3$ or splitting $20\%$ in a $2 : 3$ ratio takes less than 3 seconds.)
