Geometry and Mensuration together form the second-largest scoring block in SSC CGL—accounting for roughly 15–25% of the Quantitative Aptitude section—yet most aspirants prepare them far less systematically than arithmetic topics like percentages or ratios. Students often memorize isolated area formulas without understanding how theorems connect, and then get stuck when a single exam question blends two or three geometric properties.
The secret to fast geometry is not memorizing dozens of obscure formulas—it is pattern recognition. Almost every geometry problem in SSC CGL, CHSL, RRB NTPC, CDS, and state exams is a variation of 8–10 recurring configurations. Once you internalize these configurations and their direct shortcuts, you can solve most geometry questions in 30 to 45 seconds.
This guide organizes all high-yield configurations systematically—Triangles, Circles, Quadrilaterals, Polygons, and 3D Mensuration—with clean formulas, exam shortcuts, and step-by-step worked examples.
Part 1: Triangles
Core Area Formulas
Formula 1 (Base & Height): $\text{Area} = \frac{1}{2} \times b \times h$
Formula 2 (Heron's Formula — all three sides $a, b, c$ known):
$$s = \frac{a + b + c}{2}, \qquad \text{Area} = \sqrt{s(s - a)(s - b)(s - c)}$$
Formula 3 (Two sides & included angle $C$): $\text{Area} = \frac{1}{2}ab\sin C$
Formula 4 (Equilateral Triangle of side $a$):
$$\text{Area} = \frac{\sqrt{3}}{4}a^2 \quad \text{and} \quad \text{Height } (h) = \frac{\sqrt{3}}{2}a$$
(Memory tip: $\frac{\sqrt{3}}{4} \approx 0.433$ is handy for quick decimal approximations.)
Worked Example 1: Find the area of an equilateral triangle with side $8\text{ cm}$.
$\text{Area} = \frac{\sqrt{3}}{4} \times 8^2 = 16\sqrt{3} \approx \mathbf{27.71\text{ cm}^2}$
Worked Example 2: Find the area of a triangle with sides $13\text{ cm}$, $14\text{ cm}$, and $15\text{ cm}$.
Semi-perimeter $s = \frac{13 + 14 + 15}{2} = 21$
$\text{Area} = \sqrt{21 \times (21 - 13) \times (21 - 14) \times (21 - 15)} = \sqrt{21 \times 8 \times 7 \times 6} = \sqrt{7,056} = \mathbf{84\text{ cm}^2}$
Critical Triangle Angle & Right-Triangle Shortcuts
Interior Angle Sum: The sum of all three angles in any triangle is always $180^\circ$.
Exterior Angle Theorem: An exterior angle equals the sum of the two opposite interior angles.
Example: If two interior angles are $50^\circ$ and $70^\circ$, the exterior angle at the third vertex is immediately $50^\circ + 70^\circ = \mathbf{120^\circ}$.
Isosceles Triangle: Angles opposite equal sides are equal. If the apex angle is $\theta$, each base angle is $\frac{180^\circ - \theta}{2}$.
Right-Angled Triangle Properties (Legs $a, b$ and Hypotenuse $c$):
Pythagoras Theorem: $a^2 + b^2 = c^2$
Circumradius / Median to Hypotenuse: The median drawn to the hypotenuse is always half the hypotenuse ($R = \frac{c}{2}$).
Altitude ($h$) to Hypotenuse: $h = \frac{a \times b}{c}$
Inradius ($r$) of a Right Triangle: $r = \frac{a + b - c}{2}$
10 Must-Memorize Pythagorean Triplets
Recognizing standard triplets (and their scalar multiples) eliminates squaring and square-root calculations completely.
Base Triplet | Common Exam Multiples |
|---|---|
$(3, 4, 5)$ | $(6, 8, 10)$, $(9, 12, 15)$, $(12, 16, 20)$, $(15, 20, 25)$ |
$(5, 12, 13)$ | $(10, 24, 26)$, $(15, 36, 39)$ |
$(8, 15, 17)$ | $(16, 30, 34)$ |
$(7, 24, 25)$ | $(14, 48, 50)$ |
$(9, 40, 41)$ | $(18, 80, 82)$ |
$(11, 60, 61)$ | — |
$(12, 35, 37)$ | — |
$(20, 21, 29)$ | — |
$(16, 63, 65)$ | — |
$(28, 45, 53)$ | — |
Worked Example: A right triangle has legs of $15\text{ cm}$ and $20\text{ cm}$. Find the hypotenuse.
Spot the multiple: $(15, 20, ?) = 5 \times (3, 4, 5) \implies \text{Hypotenuse} = 5 \times 5 = \mathbf{25\text{ cm}}$.
Special Right Triangles ($30^\circ\text{-}60^\circ\text{-}90^\circ$ & $45^\circ\text{-}45^\circ\text{-}90^\circ$)
$30^\circ\text{-}60^\circ\text{-}90^\circ$ Triangle: Sides opposite $(30^\circ, 60^\circ, 90^\circ)$ are always in the ratio $1 : \sqrt{3} : 2$.
If hypotenuse $= 10 \implies$ side opposite $30^\circ = 5$, side opposite $60^\circ = 5\sqrt{3}$.
$45^\circ\text{-}45^\circ\text{-}90^\circ$ Triangle: Sides opposite $(45^\circ, 45^\circ, 90^\circ)$ are always in the ratio $1 : 1 : \sqrt{2}$.
If hypotenuse $= 8\sqrt{2} \implies$ each leg $= 8$.
Worked Example: Find the height of an equilateral triangle of side $6\text{ cm}$.
An altitude splits an equilateral triangle into two $30^\circ\text{-}60^\circ\text{-}90^\circ$ triangles with hypotenuse $6\text{ cm}$ and base $3\text{ cm}$ $\implies \text{Height} = \mathbf{3\sqrt{3}\text{ cm}}$.
The 4 Centers of a Triangle
Center | Point of Intersection | Exam-Critical Property |
|---|---|---|
Centroid ($G$) | Medians | Divides every median in the ratio $2 : 1$ from the vertex. |
Circumcenter ($O$) | Perpendicular bisectors | Equidistant from all 3 vertices ($OA = OB = OC = R$). |
Incenter ($I$) | Internal angle bisectors | Equidistant from all 3 sides ($r$); $\angle BIC = 90^\circ + \frac{\angle A}{2}$. |
Orthocenter ($H$) | Altitudes | Lies at the $90^\circ$ vertex in a right triangle; $\angle BHC = 180^\circ - \angle A$. |
Worked Example: In $\triangle ABC$, median $AD = 9\text{ cm}$ and $G$ is the centroid. Find $AG$ and $GD$.
$AG = \frac{2}{3} \times 9 = \mathbf{6\text{ cm}}$ | $GD = \frac{1}{3} \times 9 = \mathbf{3\text{ cm}}$.
Similarity & Proportionality Theorems
Area Ratio of Similar Triangles: If $\triangle ABC \sim \triangle DEF$, then:
$$\frac{\text{Area}(\triangle ABC)}{\text{Area}(\triangle DEF)} = \left(\frac{AB}{DE}\right)^2 = \left(\frac{BC}{EF}\right)^2 = \left(\frac{AC}{DF}\right)^2$$
Worked Example: Two similar triangles have corresponding sides in the ratio $3 : 5$. If the larger triangle has an area of $100\text{ cm}^2$, find the area of the smaller triangle.
$\text{Area Ratio} = 3^2 : 5^2 = 9 : 25 \implies \text{Smaller Area} = \frac{9}{25} \times 100 = \mathbf{36\text{ cm}^2}$.
Mid-Point Theorem: The segment joining the midpoints of any two sides of a triangle is parallel to the third side and exactly half its length.
Basic Proportionality Theorem (Thales' Theorem): A line drawn parallel to one side of a triangle divides the other two sides in the exact same ratio.
Part 2: Circles
Core Circle Formulas
Measurement | Formula |
|---|---|
Circumference | $2\pi r$ |
Area of Circle | $\pi r^2$ |
Arc Length ($\theta^\circ$) | $\frac{\theta}{360^\circ} \times 2\pi r$ |
Area of Sector ($\theta^\circ$) | $\frac{\theta}{360^\circ} \times \pi r^2$ |
Area of Minor Segment | $\text{Sector Area} - \text{Triangle Area} = r^2\left(\frac{\pi\theta}{360^\circ} - \frac{1}{2}\sin\theta\right)$ |
Calculation Tip for $\pi$: Use $\pi = \frac{22}{7}$ whenever $r$ is a multiple of $7$; use $\pi = 3.14$ for decimal answers; use $\pi \approx 3$ only when options are widely spaced.
The 8 Most-Tested Circle Theorems
Central Angle Theorem: The angle subtended by an arc at the center is double the angle subtended by it at any point on the remaining circumference ($\angle AOB = 2 \times \angle ACB$).
Example: If central $\angle AOB = 110^\circ$, then inscribed $\angle ACB = \mathbf{55^\circ}$.
Angles in the Same Segment: Inscribed angles subtending the same arc are always equal ($\angle APB = \angle AQB$).
Angle in a Semicircle: Any angle inscribed in a semicircle (subtended by a diameter) is always $90^\circ$.
Cyclic Quadrilateral: Opposite angles of a quadrilateral inscribed in a circle sum to $180^\circ$ ($\angle A + \angle C = 180^\circ$, $\angle B + \angle D = 180^\circ$).
Worked Example: In cyclic quadrilateral $ABCD$, $\angle A = 75^\circ$ and $\angle B = 110^\circ$.
$\angle C = 180^\circ - 75^\circ = \mathbf{105^\circ}$ | $\angle D = 180^\circ - 110^\circ = \mathbf{70^\circ}$.
Tangent-Radius Perpendicularity: A tangent at any point on a circle is perpendicular ($90^\circ$) to the radius drawn to the point of contact.
Equal Tangents from an External Point: Two tangents drawn from an external point $P$ to a circle are equal in length ($PA = PB$).
Worked Example: From external point $P$, tangent $PA = 12\text{ cm}$ and distance from $P$ to center $O$ is $13\text{ cm}$. Find the radius.
Using triplet $(5, 12, 13)$: $r = \sqrt{13^2 - 12^2} = \mathbf{5\text{ cm}}$.
Alternate Segment Theorem: The angle between a tangent and a chord through the point of contact equals the inscribed angle in the alternate segment.
Intersecting Chords & Secant-Tangent Power Theorem (SSC CGL Staple):
Two chords $AB$ and $CD$ intersecting at $P$ (inside or outside): $PA \times PB = PC \times PD$
Secant $PAB$ and Tangent $PT$ from external point $P$: $PT^2 = PA \times PB$
High-Frequency Circle Configurations
Area of a Ring (Annulus): For concentric circles of radii $R$ and $r$:
$$\text{Area} = \pi(R^2 - r^2) = \pi(R + r)(R - r)$$
Example ($R = 7\text{ cm}, r = 3\text{ cm}$): $\text{Area} = \pi(7 + 3)(7 - 3) = \mathbf{40\pi \approx 125.7\text{ cm}^2}$.
Perimeter of a Sector: $\text{Perimeter} = 2r + \text{Arc Length}$
Example ($r = 14\text{ cm}, \theta = 90^\circ$): $\text{Arc} = \frac{1}{4} \times 2 \times \frac{22}{7} \times 14 = 22\text{ cm} \implies \text{Perimeter} = 28 + 22 = \mathbf{50\text{ cm}}$.
Circle-Square Inscriptions:
Largest circle inscribed in a square of side $a \implies r = \frac{a}{2}$.
Largest square inscribed in a circle of radius $r \implies \text{Diagonal} = 2r \implies \text{Side} = r\sqrt{2}$.
Part 3: Quadrilaterals
Area & Diagonal Reference Table
Quadrilateral | Area Formula | Key Diagonal & Side Properties |
|---|---|---|
Rectangle | $l \times b$ | Diagonals are equal and bisect each other: $d = \sqrt{l^2 + b^2}$ |
Square | $a^2$ or $\frac{d^2}{2}$ | Diagonals are equal, bisect at $90^\circ$, and bisect angles: $d = a\sqrt{2}$ |
Parallelogram | $b \times h$ or $\frac{1}{2}d_1 d_2 \sin\theta$ | Opposite sides/angles equal; consecutive angles sum to $180^\circ$; diagonals bisect each other |
Rhombus | $\frac{1}{2} \times d_1 \times d_2$ | All 4 sides equal; diagonals bisect each other at $90^\circ$: $a^2 = \left(\frac{d_1}{2}\right)^2 + \left(\frac{d_2}{2}\right)^2$ |
Trapezium | $\frac{1}{2}(a + b) \times h$ | $a, b$ are parallel sides; $\text{Midsegment} = \frac{a + b}{2}$ |
Kite | $\frac{1}{2} \times d_1 \times d_2$ | Diagonals intersect perpendicularly ($90^\circ$) |
Worked Example 1 (Rhombus): A rhombus has diagonals of $16\text{ cm}$ and $12\text{ cm}$. Find its side length and area.
Half-diagonals $= 8\text{ cm}$ and $6\text{ cm} \implies \text{Side} = \sqrt{8^2 + 6^2} = \mathbf{10\text{ cm}}$.
$\text{Area} = \frac{16 \times 12}{2} = \mathbf{96\text{ cm}^2}$.
Worked Example 2 (Parallelogram via Diagonals): Diagonals of a parallelogram measure $10\text{ cm}$ and $8\text{ cm}$ and intersect at $30^\circ$. Find its area.
$\text{Area} = \frac{1}{2} \times 10 \times 8 \times \sin 30^\circ = \frac{1}{2} \times 80 \times \frac{1}{2} = \mathbf{20\text{ cm}^2}$.
Worked Example 3 (Trapezium): Parallel sides are $13\text{ cm}$ and $7\text{ cm}$ with height $8\text{ cm}$. Find the area.
$\text{Area} = \frac{1}{2}(13 + 7) \times 8 = \mathbf{80\text{ cm}^2}$.
Part 4: Polygons
Core Polygon Formulas ($n$ Sides)
Sum of All Interior Angles: $(n - 2) \times 180^\circ$
Sum of All Exterior Angles: Always $360^\circ$ (for any convex polygon)
Each Interior Angle (Regular Polygon): $\frac{(n - 2) \times 180^\circ}{n}$
Each Exterior Angle (Regular Polygon): $\frac{360^\circ}{n}$ (Note: $\text{Interior} + \text{Exterior} = 180^\circ$)
Number of Diagonals: $\frac{n(n - 3)}{2}$
Regular Polygon Quick Reference
Polygon | Sides (n) | Sum of Interior Angles | Each Interior Angle | Each Exterior Angle | Diagonals |
|---|---|---|---|---|---|
Triangle | $3$ | $180^\circ$ | $60^\circ$ | $120^\circ$ | $0$ |
Quadrilateral | $4$ | $360^\circ$ | $90^\circ$ | $90^\circ$ | $2$ |
Pentagon | $5$ | $540^\circ$ | $108^\circ$ | $72^\circ$ | $5$ |
Hexagon | $6$ | $720^\circ$ | $120^\circ$ | $60^\circ$ | $9$ |
Octagon | $8$ | $1,080^\circ$ | $135^\circ$ | $45^\circ$ | $20$ |
Decagon | $10$ | $1,440^\circ$ | $144^\circ$ | $36^\circ$ | $35$ |
Area of a Regular Polygon (side $a$): $\text{Area} = \frac{na^2}{4}\cot\left(\frac{180^\circ}{n}\right)$
Regular Hexagon Shortcut: A regular hexagon is composed of 6 identical equilateral triangles:
$$\text{Area} = 6 \times \frac{\sqrt{3}}{4}a^2 = \frac{3\sqrt{3}}{2}a^2$$
Worked Example (Side $6\text{ cm}$): $\text{Area} = 6 \times \frac{\sqrt{3}}{4} \times 36 = \mathbf{54\sqrt{3}\text{ cm}^2}$.
Part 5: 3D Mensuration Shortcuts
Volume & Surface Area Master Table
3D Solid | Volume | Curved / Lateral Surface Area | Total Surface Area |
|---|---|---|---|
Cube (side $a$, diagonal $a\sqrt{3}$) | $a^3$ | $4a^2$ | $6a^2$ |
Cuboid ($l, b, h$, diagonal $\sqrt{l^2+b^2+h^2}$) | $l \times b \times h$ | $2h(l + b)$ | $2(lb + bh + hl)$ |
Cylinder ($r, h$) | $\pi r^2 h$ | $2\pi r h$ | $2\pi r(r + h)$ |
Cone ($r, h$, slant $l = \sqrt{r^2+h^2}$) | $\frac{1}{3}\pi r^2 h$ | $\pi r l$ | $\pi r(r + l)$ |
Sphere ($r$) | $\frac{4}{3}\pi r^3$ | $4\pi r^2$ | $4\pi r^2$ |
Hemisphere ($r$) | $\frac{2}{3}\pi r^3$ | $2\pi r^2$ | $3\pi r^2$ |
Most-Tested Mensuration Scaling & Melting Shortcuts
Cube Scaling: If each side of a cube doubles ($2a$), its Surface Area becomes $4\times$ and its Volume becomes $8\times$.
Cylinder Scaling: If a cylinder's radius doubles ($2r$) and height halves ($\frac{h}{2}$), its new volume is $\pi(2r)^2\left(\frac{h}{2}\right) = \mathbf{2\pi r^2 h}$ (Volume doubles).
Cone vs. Cylinder: For the same base radius and height, $\text{Volume of Cone} = \frac{1}{3} \times \text{Volume of Cylinder}$.
Melting & Recasting Conservation: Whenever a solid is melted and recast into smaller shapes, Total Volume remains constant:
$$\text{Volume of Original Solid} = n \times \text{Volume of One Smaller Solid}$$
Worked Example: A solid metallic sphere of radius $6\text{ cm}$ is melted and recast into cones of radius $2\text{ cm}$ and height $3\text{ cm}$. How many cones are formed?
$\text{Sphere Volume} = \frac{4}{3}\pi(6)^3 = 288\pi\text{ cm}^3$
$\text{One Cone Volume} = \frac{1}{3}\pi(2)^2(3) = 4\pi\text{ cm}^3$
$\text{Number of Cones } (n) = \frac{288\pi}{4\pi} = \mathbf{72\text{ cones}}$.
